OVERVIEW

10 GHz amplified optical channel for 9/125 to 62.5/125 fibers

• Wavelength range: 1000-1600 nm
• Characteristic rms noise: 2.2 uW (10 GHz BW)
• Reference receiver capability (0.622/2.488 Gb/s or 1.063/1.250 Gb/s or 2.125/2.500 Gb/s)

20 GHz electrical channel with 3.5 mm male input

• Characteristic rms noise: 0.25 mV (12.4 GHz BW), 0.5 mV (20 GHz BW)
• Maximum input signal: ± 2 Vdc
