Overview and Features
- 4 GHz bandwidth
- 4 analog channels and 16 digital channels
- Three instruments in one: oscilloscope, logic analyzer and protocol analyzer
- 20 Mpts memory per channel to capture more data, memory upgradeable to 1 Gpts
- 20 GSa/s sampling rate and InfiniiScan advanced triggering provide more signal details
- Comprehensive compliance, protocol, and analysis applications extend measurement capabilities: Serial Protocols, FPGA Dynamic Probes, Jitter Analysis (including EZJIT), MATLAB, and more
What's included:
- 4 N2873A 500 MHz passive probes
- Flying lead set logic probe, MSO cable and calibration fixture
- Probe accessory bag (mounted on the back of the instrument)
- Keysight I/O Libraries Suite
- A power cord that complies with local standards
- Front panel cover
- Keyboard, mouse and stylus
- User's Guide and Programmer's Guide, included on the oscilloscope hard drive
- Service Guide, see Keysight.com
