Features

Characterize higher performance designs (56 Gbaud and beyond)

The N1046A remote sampling head is a module for the N1000A DCA-X mainframe. Like all Keysight DCA modules, the N1046A offers a wide range of configurations and performance options to fit your oscilloscope solution in terms of bandwidth, channel count, and functionality.

• 75, 85 or >100 GHz maximum bandwidth (upgradeable)
• Each module is equipped with 1, 2 or 4 channels (user selectable)
• Wide bandwidth and low noise sampler for analyzing 224 Gb/s high-speed signals
• Electrical Input: 1 mm female (1.0 female to 1.85 female adapter included), 250 kSa/s sample rate
