Overview and Features

• Single-/dual-channel pulse pattern generator
• 80 MHz, 10 V from 50 Ohm into 50 Ohm
• Triggerable / PLL operation selectable
• Pulse / burst / pattern modes selectable
• Variable transition times
• BNC outputs, single-ended
• Single- or dual-channel: Requires 1 or 2 output modules 81105A
