Main features:

Source or sink:

• 2,000W pulse power (±40V, ±50A);
• 200W DC power (±10V@±20A, ±20V@±10A, ±40V@±5A)
• Convenient connection of two units (series or parallel) to form a ±100A or ±80V solution
• 1pA resolution for precise measurement of extremely low leakage current
• 1μs/point (1MHz), continuous 18 - bit A/O converter for accurate transient characteristic analysis
• 1% to 100% pulse duty cycle, suitable for exciting PWM - driven devices and special - drive - type devices
• Combines a precision voltage source, current source, digital multimeter, arbitrary waveform generator, voltage or current pulse generator and measurement, electronic load, and trigger controller - a multi - functional integrated instrument
• Includes TSP®Express characteristic analysis software, LabVIEW® drivers, and Keithley's Test Script Builder (test script editor) software switching environment.
